PSS Solar Energy Battery Storage System 5KW
PSS Series is new version of household ESS energy storage system built-in a 5KW off grid solar inverter and 5.12kWh lithium-ion battery modules into one unit. This solar energy system offers an economical and self-sufficiency solution to power home appliance by storing excess clean energy during the daytime.
- 5000W
- 5.12kWh
- 208/220/230/240 VAC
- (220V~240V)±5%
- PSS Series
Details
PSS Series ESS solar power energy solar storage system
PSS series ESS energy storage system is an all-in-one household energy solution, combining an 5KW solar inverter and a 5.12KWh lithium-ion battery into one unit. PSS solar power storage systems provides an economical and self-sufficiency solution to power home appliance or equipment by storing excess clean energy during the daytime.
| Fields of application |
Suitable for the PC,router,POS machine communication processor,industrial products which for the enterprises,government,scientific research,traffic,national defense,information and education industries.
| Specifications |
| PSS-5KW |
| AC Input | |
| Rated Input Voltage | 208/220/230/240 VAC |
| Input Voltage Range | 170~280VAC(For PC);90~280VAC(For Home Appliances) |
| Frequency Rage | 50/60Hz(Auto Sensing) |
| AC Charging Current Range | 80A |
| Max. Input Current | 90A |
| PV Input | |
| Solar Charging Type | MPPT |
| PV Max. Input Power | 5.5kW |
| MPPT Tracking Voltage Range | 120-430 VDC |
| Max. PV Input Voltage | 450 VDC |
| PV Charging Current Range | 0~80A |
| Max. Charging Current | 80A |
| Output | |
| Rated Output Power | 5kW |
| Rated Output Voltage | (220V~240V)±5% |
| Output Frequency | 50/60Hz±0.1% |
| Max. Output Current | 22.7A |
| Peak Power | 10000VA |
| Overload Capacity | Battery Mode: 1min@102%~110% Load ; 10s@110%~130%Load; 3s@130%~150% Load ; 200ms@>150% Load |
| Peak Efficiency | >94% battery mode >99% line mode |
| Transfer Time | 10ms |
| Battery | |
| Battery Energy | 5.12kWh |
| Cell technology | LiFePO4 |
| DOD | 80% |
| Product General Data | |
| Designed Life-span cycle | 6000 |
| Communication Interface | RS232, RS485, CAN |
| Display | LED Screen |
| Parallel Interface | N/A |
| Operation Environment Temperature | 0~40C |
| Storage Environment Temperature | -15~60 C |
| Environment Humidity | 20%~95% |
| Operation Altitude | <3000m |
| Cooling Mode | Active Cooling |
| Noise Emission | <50db |
| Performance Characteristics |
LEP battery with more than 6,000 cycles with 80% DOD
Easy installation, floor mount or wall mount
Built-in MPPT solar change controller
Selectable input voltage range for PC and home appliance
Support communication interface RS232, RS485, CAN
